PRODUCT FEATURES
Voltage /Frequency:The voltage/frequency of the single-phrase motor is 200V/50Hz,and that of the three-phrase motor is 380V/50Hz.
The applicable environment temperature of the fan motors used in condensers is from -30℃ to +60℃ ，and that of the fan motors used in evaporators is from -40℃ to +60℃
| PACKAGING ANALYSIS | 1/PCS | ||
| UNIVERSAL MODEL | CUSTOMIZED | ||
| Pattern | Quantity requirement | Pattern | Quantity requirement |
| Paper box | 100 pcs | Custom color box | 500 pcs |
| Neutral famous brand | Customized famous brand | ||
| TYPE | VOLTAGE | FREQUENCY | RATED CURRENT | INPUT | SPEED | AIR VOLUME |
| V | Hz | A | W | r/min | m³/h | |
| YWF2E-200-5 | 220 | 50 | 0.25 | 55 | 2500 | 790 |
| YWF2E-200-7 | 220 | 50 | 0.25 | 55 | 2500 | 885 |
| YWF2D-200-5 | 380 | 50 | 0.18 | 65 | 2500 | 790 |
| YWF2D-200-7 | 380 | 50 | 0.18 | 65 | 2500 | 885 |
| YWF-4E-200 | 220 | 50 | 0.20 | 40 | 1400 | 500 |
| 220 | 60 | 0.20 | 42 | 1700 | 600 | |
| YWF2E-250-5 | 220 | 50 | 0.5 | 110 | 2400 | 1300 |
| YWF2E-250-7 | 220 | 50 | 0.5 | 110 | 2400 | 1450 |
| YWF2D-250-5 | 380 | 50 | 0.21 | 100 | 2400 | 1300 |
| YWF2D-250-7 | 380 | 50 | 0.21 | 100 | 2400 | 1450 |
| YWF-4E-250 | 220 | 50 | 0.22 | 45 | 1400 | 860 |
| 220 | 60 | 0.25 | 55 | 1700 | 1015 | |
| YWF-4D-250 | 380 | 50 | 0.17 | 45 | 1400 | 860 |
| 380 | 60 | 0.15 | 45 | 1700 | 1015 | |
| YWF2E-300-7 | 220 | 50 | 0.65 | 140 | 2500 | 2400 |
| YWF2D-300-7 | 380 | 50 | 0.28 | 150 | 2500 | 2400 |
| YWF4E-350 | 220 | 50 | 0.65 | 135 | 1380 | 2450 |
| 220 | 60 | 0.78 | 170 | 1600 | 2830 | |
| YWF4E-350EX | 220 | 50 | 0.80 | 180 | 1380 | 3280 |
| YWF4D-350EX | 380 | 50 | 0.45 | 180 | 1380 | 3280 |
| YWF4E-400 | 220 | 50 | 0.82 | 180 | 1380 | 3980 |
| 220 | 50 | 1.2 | 250 | 1550 | 4670 | |
| YWF4D-4000EX | 380 | 50 | 0.58 | 230 | 1380 | 4600 |
| YWF6E-450 | 220 | 50 | 0.7 | 140 | 920 | 4400 |
| YWF4E-500EX1 | 220 | 50 | 2.65 | 500 | 1400 | 8450 |
| YWF4D-500EX2 | 380 | 50 | 1.6 | 700 | 1360 | 8900 |
| YWF4D-550 | 380 | 60 | 1.45 | 750 | 1550 | 10100 |
| YWF6D-600 | 380 | 50 | 1.5 | 480 | 900 | 9380 |
| YWF6D-630 | 380 | 50 | 1.5 | 550 | 900 | 11460 |
| YWF6D-710 | 380 | 50 | 2 | 1100 | 910 | 15380 |
| 380 | 50 | 1.4 | 750 | 750 | 13560 | |
| YWF6D-800 | 380 | 50 | 3.25 | 1300 | 920 | 21550 |
| 380 | 50 | 1.68 | 930 | 770 | 17780 | |
| YWF6D-900 | 380 | 50 | 3.25 | 1400 | 920 | 26000 |
| 380 | 50 | 1.7 | 940 | 750 | 21800 |
